| Stirrup Geometry | Hook Specs & Extension Requirements | BS / Metric Shape Codes | US / LATAM Classification | Typical Application |
|---|---|---|---|---|
| Closed Rectangular Stirrup | 90° / 135° hooks, extension ≥ 6d (or 75 mm) | Shape 51 / 60 | Closed Tie | Standard beam & column shear reinforcement |
| Seismic Confinement Stirrup | 135° dual seismic hooks, extension ≥ 10d (and ≥ 75 mm) | Shape 51 (Seismic) | Seismic Hook Tie | High-seismic zone column core confinement |
| U-Shape Open Stirrup | 90° hooks, extension ≥ 12d | Shape 21 / 33 | U-Stirrup | Tie beams, raft foundation edges, slab edge links |
| Cross Tie / Single Link | 135° & 90° (or dual 135°) hooks, extension ≥ 10d | Shape 11 / 41 | Crosstie | Shear wall boundary elements, double-layer rebar ties |
| Circular / Spiral Stirrup | Lap splice ≥ 48d or 135° anchorage hooks | Shape 75 / 77 | Continuous Spiral | Pile cages, circular piers & columns |
| Rebar Nominal Diameter | Imperial / ASTM Equivalent | Thread Spec & Pitch | Coupler OD × Length | Applicable Rebar Grade |
|---|---|---|---|---|
| 14 mm | - | M14 × 2.0 mm | 22 mm × 40 mm | Grade 400 / 500 / B500B |
| 16 mm | #5 (5/8") | M16 × 2.0 mm | 25 mm × 45 mm | Grade 400 / 500 / B500B / Gr 60 |
| 18 mm | - | M18 × 2.5 mm | 28 mm × 48 mm | Grade 400 / 500 / B500B |
| 20 mm | #6 (3/4") | M20 × 2.5 mm | 31 mm × 50 mm | Grade 400 / 500 / B500B / Gr 60 |
| 22 mm | #7 (7/8") | M22 × 2.5 mm | 34 mm × 55 mm | Grade 400 / 500 / B500B / Gr 60 |
| 25 mm | #8 (1") | M25 × 3.0 mm | 38 mm × 60 mm | Grade 400 / 500 / B500B / Gr 60 |
| 28 mm | #9 (1-1/8") | M28 × 3.0 mm | 42 mm × 68 mm | Grade 400 / 500 / B500B / Gr 60 |
| 32 mm | #10 (1-1/4") | M32 × 3.5 mm | 48 mm × 75 mm | Grade 400 / 500 / B500B / Gr 60 |
| 36 mm | #11 (1-3/8") | M36 × 3.5 mm | 53 mm × 82 mm | Grade 400 / 500 / B500B / Gr 60 |
| 40 mm | #12 (1-1/2") | M40 × 4.0 mm | 58 mm × 90 mm | Grade 400 / 500 / B500B / Gr 60 |
We cater to commercial, institutional, multi-story, industrial, chemical plants, residential, foundation, bridge, and modular structures.
With 26 years of experience and a monthly production capacity of over 5,000 tons, we are committed to delivering the highest customer satisfaction through quality, consistency, and seamless workflows.
