HDPE Drainage Pipe

Introduction:

Yoshine’s HDPE Drainage Pipe, also known as PE Sewer Pipe, Corrugated Stormwater Pipe, or High-Density Polyethylene Drainage Tubing, is a versatile solution engineered for gravity-flow wastewater management systems. Designed to meet global standards such as EN 13476, ASTM F2648, and GB/T 19472.2, this pipe is widely used in:

• Municipal sewage networks (HDPE Sewage Pipe)

• Stormwater drainage systems (PE Stormwater Pipe)

• Agricultural subsurface drainage (Agricultural Drain Pipe)

• Industrial effluent discharge (Industrial Wastewater Conduit)

Crafted from PE100 resin, our pipes combine high ring stiffness (SN8–SN32) with exceptional chemical resistance, making them ideal for buried, trenchless, or exposed installations.

Inquiry Now Add To Cart

Product Details

Outer Diameter (DN/ID, mm)	Ring Stiffness (SN)	Material Grade	Connection Type
110	SN8	PE100	Socket / Butt Fusion
160	SN8 / SN12.5	PE100	Electrofusion / Butt
200	SN12.5 / SN16	PE100	Socket / Flange
250	SN8 – SN16	PE100	Butt Fusion / Mechanical
315	SN16	PE100	Welding / Flange
400	SN16 / SN24	PE100	Welding / Flange
500	SN24	PE100	Welding / Flange
630	SN32	PE100	Welding / Flange

Notes:

• Customizable dimensions (DN100–DN3000), lengths (6m/12m), colors (black, blue stripe, gray), and fittings.

• Higher SN grades (up to SN32) available for heavy-load applications.

Customization & Processing Services

Tailored Product Specifications:

• Custom diameters (DN100–DN3000), lengths (6m/12m or as required), wall thicknesses (SDR), and colors (black, blue stripe, gray).

• Fittings customization: Elbows, reducers, tees, flanges, manholes, and adapters for compatibility with local systems.

Technical Support & Documentation:

• Detailed installation guidelines (PDF/video) for butt fusion, electrofusion, and flange connections.

• Provide welding parameters and on-call remote assistance for critical steps.

Packaging:

OEM packaging with client-specific labeling (branding, barcodes, etc.).

Prefabricated Modules (Optional):

Pre-welded pipe assemblies (e.g., manifolds, bypass sections) to reduce on-site labor.

Product Features

• High Ring Stiffness (SN8–SN32): Resists soil pressure and heavy traffic loads.

• Chemical Resistance: Compatible with sewage, saltwater, and industrial effluents.

• UV-Stabilized: Suitable for exposed or buried installations.

• Leak-Free Joints: Seamless welding (butt/electrofusion) prevents root intrusion.

• Low Maintenance: 50+ years service life with minimal upkeep.

• Compliance: Meets GB/T 19472.2, EN 13476, and ASTM F2648 for drainage systems

Quality Assurance

ISO 9001-Certified Production: Traceable resin batches and strict process controls.

Testing: Each pipe undergoes testing for Hydrostatic strength (for pressure-rated variants), ring stiffness (SN), impact resistance, and dimensional checks.

Documentation: Mill certificates, inspection reports, and compliance with ASTM F2648, EN 13476 and GB/T 19472.2.

Advantages

Trusted for Infrastructure Worldwide
YOSHINE HDPE pipes are widely used in municipal sewage, highway drainage, landfill leachate systems, and mining discharge..

Superior Load-Bearing Capacity
With SN8–SN32 grades, our pipes withstand backfill pressure and dynamic loads in buried environments.
Corrosion & Abrasion Resistance
Ideal for aggressive wastewater, mining slurry, and coastal drainage.
Rapid Installation
Lightweight design reduces trenching costs and enables no-dig (trenchless) methods.
Eco-Friendly
100% recyclable and energy-efficient production.

International Naming & Equivalent Terms

Region / Standard	Equivalent Name / Term
China (GB/T 19472.2)	HDPE排水管 / 聚乙烯排污管
Europe (EN 13476)	HDPE Structured Wall Drainage Pipe
International (ASTM F2648)	HDPE Drainage Pipe / PE Sewer Pipe
General Use	HDPE Corrugated Pipe / PE Stormwater Pipe
